Using Deep Learning f or Detecting Spoofing Attacks on Speech Signals Alan Godoy 1 , 2 , Fl ´ avio Sim ˜ oes 1 , J os ´ e Augusto Stuc hi 1 , Mar cus de Assis Angeloni 1 , M ´ ario Uliani 1 , Ricar do V iolato 1 1 CPqD Foundation, Campinas, Brazil 2 Uni versity of Campinas, Campinas, Brazil { amello,simoes,jastuchi,massis,uliani,rviolato } @cpqd.com.br Abstract It is well known that speak er verification systems are subject to spoofing attacks. The Automatic Speak er V erification Spoofing and Countermeasures Challenge – ASVSpoof2015 – provides a standard spoofing database, containing attacks based on syn- thetic speech, along with a protocol for experiments. This pa- per describes CPqD’ s systems submitted to the ASVSpoof2015 Challenge, based on deep neural networks, working both as a classifier and as a feature extraction module for a GMM and a SVM classifier . Results show the validity of this approach, achieving less than 0.5% EER for kno wn attacks. Index T erms : Speaker V erification, Spoofing Countermea- sures, Deep Neural Networks 1. Intr oduction Biometric spoofing is usually described as a direct attack per- petrated against a biometric authentication system by present- ing it a f ake (forged or copied) biometric sample. Anti-spoofing refers, therefore, to countermeasures designed to detect and pre- vent these attacks [1]. In the last few years, many studies have shown that even state-of-the-art automatic speaker verification (ASV) systems are vulnerable to such attacks, which can be based on a vari- ety of techniques, including voice conv ersion, speech synthe- sis, artificial signals, impersonation, and replay [1]. Although most of these studies proposes countermeasures too, they usu- ally are based on prior knowledge about the attack method, what is clearly unrepresentative of real world scenarios. Additionally , each one is also based on its own database, protocol and met- rics, making it difficult to perform a proper analysis of results and restricting fair comparison among them [2]. The recent Automatic Speaker V erification Spoofing and Countermeasures Challenge, ASVSpoof2015 1 , which focused on spoofing attacks based on synthetic speech, pro vided the first standard spoofing database along with a protocol for ex- periments. Differently from pre vious works, 10 different voice con version and speech synthesis algorithms were used to gener- ate the database, but only 5 of them were known in advance in order to train spoofing detection algorithms [3]. This paper de- scribes the systems based on neural networks submitted to the challenge and analyze the obtained results. Deep Neural Networks (DNN) have been widely used in a variety of research fields, such as image classification [4, 5], natural language processing [6] and information retriev al [7]. In the speech processing community , DNN hav e been applied to speech recognition [8], speech synthesis [9, 10] and also to speaker recognition [11, 12]. 1 http://www.spoofingchallenge.org/ One straightforward application of a DNN for spoofing de- tection is to use it as a classifier , whose input data can be either raw audio [13] or features pre viously extracted from the audio files. A natural choice for audio pre-processing is to use features prov en to yield good results in speaker recognition and spoof- ing detection tasks, such as traditional Mel Frequency Cepstral Coefficients (MFCC) [14] and Modified Group Delay Cepstral Coefficients (MGDCC) [15], which ha ve been broadly used not only in combination with neural networks, but also with a hand- ful of other classification algorithms. In problems like spoofing detection, a DNN can also be em- ployed as a feature extraction module itself, by means of a bot- tleneck approach [16]. In this case, a network, initially trained for re gression or classification, has its final layers removed, and the output of its last remaining layer is used as a new representa- tion of the input data for future classification [13]. The network can receiv e as input a pre-processed feature vector , a high-level full representation of the signal (using, for instance, the Fast Fourier transform) or e ven the raw audio. In this work, we used the high-lev el representation approach, as described in Section 3. The paper is organized as follows: Section 2 presents a brief description of neural networks. Section 3 explains the methods applied. Section 4 presents and discusses results obtained on the ASVspoof2015 challenge. Finally , Section 5 draw some conclusions, as well as points to topics for future research. 2. Neural Networks The submitted systems are based on a Deep Learning approach. A deep neural network (DNN) is an artificial neural network with more than one hidden neuronal layer between its inputs and outputs [17]. The DNN concept can be implemented us- ing many different architectures, such as Con volutional Neural Networks (CNN) [18], Autoencoders [19], and Multilayer Per- ceptrons (MLP) [20]. In a Multilayer Perceptron, tipically , each neuron j in a hid- den layer l employs a sigmoid function, such as the logistic function or hyperbolic tangent, to map the total input x l j , re- ceiv ed from the layer l − 1 , to an output y l j , that is sent to the following layer , l + 1 . x l j = b l j + X 1 ≤ i ≤ N l − 1 w l i,j y l − 1 i (1) y l j = l og istic ( x l j ) (2) where N l − 1 is the number of neurons in layer l − 1 , y l − 1 i is the output of neuron i on previous layer , w l i,j is the connection weight between neuron i from layer l − 1 and neuron j from layer l , and b l j is the bias of neuron j of the current layer [17]. One of the major DNN applications is for multiclass classi- fication problems. In this context, a softmax nonlinear function can be used in the network output layer to conv ert inputs x out j , into a class probability , p j : p j = exp( x out j ) P 1 ≤ k ≤ N out exp( x out k ) (3) where N out is the number of neurons in the output layer , which is equal to the number of possible classes. In this case, the network output p j will indicate the likelihood of the input fed to the network belonging to the j -th class [17]. 3. Method 3.1. Feature Extraction Aiming at detecting if an audio is authentic or not, a deep neu- ral network based on a multilayer perceptron architecture was used as a feature extraction module. In a bottleneck approach, the network output layer is removed and the activ ations of the last hidden layer neurons are treated as new features for future classification. Figure 1 shows how audio was processed, from feature extraction to network supervised training. Instead of feeding raw signal directly as input to the net- work, a pre-processing step was performed in order to trans- form input signals into sequences of feature vectors. This de- cision was based on preliminary tests, which indicated such a step was able to improve the learning rate and allowed the use of more compact networks. Therefore, each signal file is di- vided into a sequence of 20 ms consecutive non-overlapping frames. No window function is applied. In parallel, a voice ac- tivity detection method based on ITU G.729B [21] is applied, so each frame is classified as speech/non-speech and only speech frames are preserved. Different representations were tested as input for the MLP , including the raw speech frame itself, MFCC, MGDCC and Discrete Fourier Transform (DFT) coefficients. Nev ertheless, better results were achiev ed with the Discrete Cosine T rans- form (DCT) coefficients. The DCT has the energy compaction property , which concentrates most of the signal information in a few lo w-frequency components [22]. For this reason, the first 128 DCT coef ficients are used as feature for each acti ve speech frame. In order to avoid loss of long term information that can pos- sibly be used to distinguish spoofing attacks, when an input is presented to the MLP , each central speech frame is surrounded by its ten previous frames and the ten following ones, including silence frames [11]. Thus, a vector with 2688 features is used as network input. The backpropagation algorithm, in conjunction with the Stochastic Gradient Descent optimization technique [20], was applied to train the network to classify whether the input rep- resents an authentic (human) or spoofed audio frame. Ground truth consists of a label indicating if the input audio is authentic or belongs to one of fi ve spoofing categories, named S1, S2, S3, S4 or S5 [2]. Preliminary experiments indicated that using only two classes – spoofing and human – as output led to poor perfo- mance in class S1. One hypothesis is that this could happen because S1 distinguishes from other attacks since it is based on a unit selection algorithm, which concatenates pieces of au- thentic signal to create a new audio. T o deal with this, it was D C T E xt r ac t 20 ms f r am e s Vo i c e a c t i v i t y de t e c t i o n A ud i o file S e l e c t ac t i v e f r am e s T r ai n a M LP ne t wo r k E xt r ac t f i r st 128 c o e f f i c i e nt s R e t r i e v e coeffici ents f r o m pr e v i o us 10 f r am e s F o r e a c h f r a me R e t r i e v e c o e f f i c i e nt s f r o m ne xt 10 f r am e s E xt r ac t l as t hi dd e n l ay e r ac t i v at i o n i np ut s G r o un d t r ut h o ut pu t s T r ai n a c l as si f i e r Us e M LP as c l as si f i e r Figure 1: Basic flowchart used for spoofing detection decided to dri ve the network training to wards distinguishing S1 from the other spoofing attacks, increasing the relev ance (on network performance) of detecting borders between pieces of authentic speech. Thus, three classes were created, as depicted in T able 1: authentic human speech (100), S1 spoofing attack (010) and other spoofing attacks (001). Figure 2 shows the MLP deep architecture used in this pa- per . 1024 neurons were used in the first hidden layer , 512 in the second hidden layer and 32 in the last one. The last hidden layer is artificially small in order to create a bottleneck, which compress signal information useful for spoofing classification in a low-dimensional representation [16]. Each hidden layer uses the logistic function as acti vation. The output consists of 3 neurons, each one with softmax activ ation function, returning a real number between 0 and 1. After finishing the netw ork train- ing, the output layer was remo ved and the activations of the last hidden layer neurons were used as new output, extracting the bottleneck features, as indicated in Figure 2. T able 1: MLP classes output meanings. y0 y1 y2 Meaning 1 0 0 human 0 1 0 S1 attack 0 0 1 S2, S3, S4, S5 attacks 1 2 2 10 1 2 2 9 1 2 2 5 … … … 1 2 3 … x 0 x 1 x 2668 y 0 y 1 y 2 b o t t l e ne c k f e at ur e s Figure 2: MLP used for feature extraction and classification 3.2. Classification Three different classifiers were tested: Support V ector Ma- chines (SVM), Gaussian Mixture Models (GMM) and Multi- layer Perceptron. In the cases of the SVM and the GMM clas- sifiers, feature extraction took an additional step. Since each audio file has a different duration and, thus, a different number of frames, feature vectors ov er all frames were a veraged so that each file was represented by a single fixed-size 32-dimensional feature vector [23]. A SVM classifier [24] based on the Radial Basis Function (RBF) kernel was generated. Samples from the training set were computed and used to train the SVM-RBF . All spoofing attacks were considered as a single negati ve class for training. The SVM-RBF classifier parameters C (controls the cost of misclassification on the training data) and γ (parameter of a Gaussian kernel to handle nonlinear classification) were tuned by performing grid search with K-fold cross-v alidation over the train set, using 5 folds. V alues of 0.001, 0.01, 0.1, 1.0, 10.0, 100.0, 1000.0 and 10000.0 were searched both for C and γ . Optimum parameters were chosen aiming at minimizing the a v- erage equal error rate (EER) over all 5 folds. After this search, optimum v alues of C = 0 . 1 and γ = 10 were found and the SVM-RBF classifier was retrained with the whole training set. SVM-RBF outputs vary in the interv al [0 . 0 , 1 . 0] and represent the likelihood of the test sample belonging to positiv e class, i.e., authentic speech audio. For the GMM based classifier, two GMMs were trained, one with authentic audios and another with spoofed audios. The following number of Gaussian mixtures were tested: 4, 8, 32, 64, 128, 256 and 512, wherein 8 mixtures gave the lo west EER on the development set. The classifier output is given by the log-likelihood ratio of authentic GMM with respect to spoofing GMM. Figure 3 shows the log-likelihood ratio (score) distribution obtained on the development set when a 8-mixture GMM was employed to classify the bottleneck features. Score values v ary in the interval [ −∞ , + ∞ ] and the higher the v alue, the higher the probability of the tested sample being authentic. The figure clearly shows this strategy provided a good separation over the dev elpment set. A similar behavior was verified for the SVM- RBF classifier . 2000 1500 1000 500 0 500 1000 1500 2000 0 500 1000 1500 2000 2500 human spoofing Figure 3: Scores distribution for spoofing (green) and authentic (blue) audios on the development set when using a GMM with 8 gaussians and bottleneck features The third and last tested approach consisted of using the MLP trained for feature extraction directly as a classifier, with- out the removal of the output layer . In this case, the feature extraction was mer ged with the classification step. As the network last layer returns three values using the soft- max function, according to presented in Figure 2, only y 0 is considered, since it represents the likelihood of being an au- thentic speech. Thus, values for this third approach vary in the interval [0 . 0 , 1 . 0] . A score ( y 0 ) was then calculated for each frame in the audio file, generating a score array for the entire audio. This array was used to compute a unique score for the audio sample. T o do so, aiming at removing outliers within the audio file, the first 15% lower array values are removed as well as the 25% higher values. The remaining 60% of the scores were then av eraged, resulting in the final score. These three aproaches were, then, applied to the ev aluation set, which contained samples comprising both known and un- known attacks. Results are presented in the next section. 4. Results and Analysis Results obtained for the three tested systems are summarized in T able 2. According to challenge rules, the adopted metric is the EER. For more details on what that means and how it is calculated, please refer to the contest ev aluation plan [3]. It can be seen that: • the SVM-RBF classifier showed the best performance T able 2: EER r esults (%) obtained on development set and on evaluation set for known and unknown attacks. Classifier Dev Set Known Unkno wn All SVM 0.491 0.412 13.026 6.719 GMM 0.658 0.443 12.796 6.620 MLP 0.631 0.464 12.589 6.527 for known attacks, while the unknown attacks were bet- ter detected by the MLP classifier . Howe ver , EER values are v ery close, which means that the choice of the classi- fier is less determinant for the overall performance than the feature extraction mechanism itself. • all three systems performed very well for the known at- tacks, which sho ws that the network was successfull in capturing the pattern of attacks learned during training. • most of the unknown attacks were correctly detected; howe ver a clear degradation of performance can be ob- served when error rates of known and unknown attacks are contrasted. • when considering only the five unkno wn attacks discrim- inated by method used (these results are not shown here due to space reasons), the proposed method obtained good results (EER near to 1%) in three of them. Re- sults for attacks S8 (a tensor -based v oice con version) and S10 (a speech synthesis algorithm implemented using the open source MaryTTS system), howe ver , indicate a poor performance, with EERs of 26.8% and 31.7%, re- spectiv ely . One hypothesis for the degradation observed in classifiers’ performances for ev aluation set is the occurence of overfitting to noise present in training samples. This situation can be verified by the existence of a significant difference in error rates ev en when training and testing samples are dra wn from the same dis- tribution. That is not what the results presented here sho w , since performance in the de velopment set is close to the performance for known attacks in e valuation set. The second hypothesis is lack of generalization capacity , which means that some of the distincti ve features learned by the network and the classifiers are not related to what distinguishes an authentic recording from spoofing attacks in general, b ut are rather due to patterns only observed in the kno wn attack sam- ples, i.e., specific characteristics of synthesis and con version al- gorithms used during training step. It was also verified after the submission that man y spoofing audios available on the training and dev elopment sets present descontinuity in low frequency noise, mainly in the range 0 to 100 Hz. Figure 4 shows the problem. In this case, as 128 DCT coefficients was used as DNN input, the first coefficients will indicate this discontinuity and the network will learn this characteristic as a rele vant feature to distinguish authentic from spoofing audios, degrading the network’ s generalization capac- ity when audios without this discontinuity are presented. Even though some degradation of performance is expected, the results obtained show that there is room for improvements, since the nature of unkno wn attacks is not inherently different from that of the known ones. 5. Conclusions The study presented here comprises the results obtained, along with the description of the systems implemented by CPqD for Figure 4: Low frequency noise discontinuity av ailable on train- ing and dev elopment set (0 to 1000 Hz in vertical axis) the Automatic Speaker V erification Spoofing and Countermea- sures Challenge (ASVSpoof2015), held as a special session in INTERSPEECH 2015. The main goal of the challenge was the detection of spoofing attacks based on sinthesized and trans- formed speech. A speech feature extraction framew ork based on deep neu- ral networks for spoofing detection is presented. The network can be used as a classifier itself or can be viewed as a bottle- neck feature extractor feeding other classifiers. T wo different classifiers were tested: a Gaussian Mixture Model and a Sup- port V ector Machine with the radial basis function. The proposed systems were trained with the training set and tested on two different e valuation sets: one with attacks similar to those presented during training and another with unknown attacks, just as described in the ev aluation plan. The use of a DNN as a feature extractor is of particular interest, as the generated features are fine-tuned to provide a good representation specifically for the problem to be solved, be it spoofing detection, speaker/speech recognition or other tasks. Howe ver , these features are highly dependent on the training samples and they can learn any bias present in this set. Thus the careful design of large and div erse datasets is ev en more relev ant when using this kind of feature. Performance for the known attacks was satisfactory ( E E R < 0 . 5% ), indicating the adequacy of the proposed strategies. Results obtained for the unknown attacks were also promising. For some of the new attacks, ho wever , the detection strategy had poor performance. This could be easily overcome with training data composed by samples generated by a more di- verse attack techniques. In addition to an improved training set, the use of alternativ e forms of parametrization of the input au- dio in the neural network could be beneficial. Representations that make the speech phase spectrum more e vident are specially interesting, as the use of such information proved to be highly successful in literature for spoofing detection [15]. Lastly , in future work, other network architectures, like Con volutional Neural Networks, should be tested in order to study which of them is able to provide better detection of un- known attacks, an ability extremely rele vant in real-world appli- cations, as rarely the techniques used by fraudsters for identity theft are known in adv ance. 6. Acknowledgements W e would like to gratefully thank MSc Christopher Dane Shulby for this paper revie w and helpful comments. 7. Refer ences [1] N. Evans, T . Kinnunen, and J. Y amagishi, “Spoofing and counter - measures for automatic speaker verification. ” in INTERSPEECH , 2013, pp. 925–929. [2] Z. Wu, T . Kinnunen, N. Evans, J. Y amagishi, C. Hanilc ¸ i, M. Sahidullah, and A. Sizov , “ Asvspoof 2015: the first auto- matic speaker verification spoofing and countermeasures chal- lenge, ” in INTERSPEECH 2015 – 16 th Annual Conference of the International Speech Communication Association, September 6– 10, Dr esden, Germany , Proceedings , 2015, p. Submitted. [3] Z. W u, T . Kinnunen, N. Ev ans, and J. Y amagishi, “ Asvspoof 2015: Automatic speaker verification spoofing and countermea- sures challenge evaluation plan, ” T raining , vol. 10, no. 15, p. 3750, 2014. [4] K. He, X. Zhang, S. Ren, and J. Sun, “Delving deep into rectifiers: Surpassing human-lev el performance on imagenet classification, ” arXiv pr eprint arXiv:1502.01852 , 2015. [5] S. Ioffe and C. Szegedy , “Batch normalization: Accelerating deep network training by reducing internal covariate shift, ” arXiv pr eprint arXiv:1502.03167 , 2015. [6] R. Collobert and J. W eston, “ A unified architecture for natural lan- guage processing: Deep neural networks with multitask learning, ” in International Conference on Machine Learning (ICML) , 2008, pp. 160–167. [7] P . Huang, X. He, J. Gao, L. Deng, A. Acero, and L. Heck, “Learn- ing deep structured semantic models for web search using click- through data, ” in Association for Computing Machinery (ACM) International Conference Information and Knowledge Manage- ment (CIKM) , 2013. [8] G. Dahl, D. Y u, L. Deng, and A. Acero, “Context-dependent pre- trained deep neural networks for large-vocabulary speech recog- nition, ” vol. 20, no. 1, pp. 30–42, 2012. [9] H. Zen, A. Senior , and M. Schuster , “Statistical parametric speech synthesis using deep neural networks, ” in Acoustics, Speech and Signal Pr ocessing (ICASSP), 2013 IEEE International Confer- ence on . IEEE, 2013, pp. 8012–8016. [10] S. Kang, X. Qian, and H. Meng, “Multi-distribution deep belief network for speech synthesis, ” in Acoustics, Speech and Signal Pr ocessing (ICASSP), 2013 IEEE International Conference on . IEEE, 2013, pp. 7962–7966. [11] E. V ariani, X. Lei, E. McDermott, I. L. Moreno, and J. Gonzalez- Dominguez, “Deep neural networks for small footprint text- dependent speaker verification, ” in Acoustics, Speech and Signal Pr ocessing (ICASSP), 2014 IEEE International Conference on . IEEE, 2014, pp. 4052–4056. [12] Y . Lei, N. Scheffer , L. Ferrer, and M. McLaren, “ A nov el scheme for speaker recognition using a phonetically-aware deep neural network, ” in Acoustics, Speech and Signal Pr ocessing (ICASSP), 2014 IEEE International Conference on . IEEE, 2014, pp. 1695– 1699. [13] H. Lee, P . Pham, Y . Largman, and A. Y . Ng, “Unsupervised fea- ture learning for audio classification using con volutional deep be- lief networks, ” in Advances in neural information processing sys- tems , 2009, pp. 1096–1104. [14] S. Davis and P . Mermelstein, “Comparison of parametric repre- sentations for monosyllabic w ord recognition in continuously spo- ken sentences, ” Acoustics, Speech and Signal Processing , IEEE T ransactions on , vol. 28, no. 4, pp. 357–366, 1980. [15] Z. Wu, X. Xiao, E. S. Chng, and H. Li, “Synthetic speech de- tection using temporal modulation feature, ” in Acoustics, Speech and Signal Processing (ICASSP), 2013 IEEE International Con- fer ence on . IEEE, 2013, pp. 7234–7238. [16] D. Y u and M. L. Seltzer , “Improv ed bottleneck features using pre- trained deep neural networks. ” in INTERSPEECH , vol. 237, 2011, p. 240. [17] G. Hinton, L. Deng, D. Y u, G. E. Dahl, A.-r . Mohamed, N. Jaitly , A. Senior, V . V anhoucke, P . Nguyen, T . N. Sainath et al. , “Deep neural netw orks for acoustic modeling in speech recognition: The shared views of four research groups, ” Signal Processing Maga- zine, IEEE , vol. 29, no. 6, pp. 82–97, 2012. [18] O. Abdel-Hamid, L. Deng, and D. Y u, “Exploring conv olutional neural network structures and optimization techniques for speech recognition. ” in INTERSPEECH , 2013, pp. 3366–3370. [19] P . V incent, H. Larochelle, I. Lajoie, Y . Bengio, and P .-A. Manzagol, “Stacked denoising autoencoders: Learning useful representations in a deep network with a local denoising criterion, ” J. Mach. Learn. Res. , vol. 11, pp. 3371–3408, Dec. 2010. [Online]. A vailable: http://dl.acm.org/citation.cfm? id=1756006.1953039 [20] S. O. Haykin, Neural networks and learning machines . Pearson Education Upper Saddle Riv er , 2009, vol. 3. [21] A. Benyassine, E. Shlomot, H.-Y . Su, D. Massaloux, C. Lamblin, and J.-P . Petit, “Itu-t recommendation g. 729 annex b: a silence compression scheme for use with g. 729 optimized for v . 70 dig- ital simultaneous voice and data applications, ” Communications Magazine, IEEE , vol. 35, no. 9, pp. 64–73, 1997. [22] N. Ahmed, T . Natarajan, and K. R. Rao, “Discrete cosine trans- form, ” Computers, IEEE T ransactions on , v ol. 100, no. 1, pp. 90– 93, 1974. [23] M. J. R. F . Correia, “ Anti-spoofing: Speaker verification vs. voice con version, ” Master’ s thesis, Instituto Superior T ´ ecnico Lisboa, 2014. [24] C. Cortes and V . V apnik, “Support-vector networks, ” Machine Learning , vol. 20, no. 3, pp. 273–297, 1995. [Online]. A vailable: http://dx.doi.org/10.1007/BF00994018
