RISC and CISC

FIGURE 9 MIPS MICROPROCESSOR ------------------------------------------------------------------------------------- ----------------------------------------------------------------- ----------------------------------------------FIGURE 12 SUPERH MICROPROCESSOR -------------------------------------------------------------------------------- -----------------------------------------------------RISC AND CISC General i

The dominant architecture in the PC market, the Intel IA-32, belongs to the Complex Instruction Set Computer (CISC) design. The obvious reason for this classification is the “complex” nature of its Instruction Set Architecture (ISA). The motivation for designing such complex instruction sets is to provide an instruction set that closely supports the operations and data structures used by Higher-Level Languages (HLLs). However, the side effects of this design effort are far too serious to ignore.

The decision of CISC processor designers to provide a variety of addressing modes leads to variable-length instructions. For example, instruction length increases if an operand is in memory as opposed to in a register.

a. This is because we have to specify the memory address as part of instruction encoding, which takes many more bits.

b. This complicates instruction decoding and scheduling. The side effect of providing a wide range of instruction types is that the number of clocks required to execute instructions varies widely.

c. This again leads to problems in instruction scheduling and pipelining.

For these and other reasons, in the early 1980s designers started looking at simple ISAs. Because these ISAs tend to produce instruction sets with far fewer instructions, they coined the term Reduced Instruction Set Computer (RISC). Even though the main goal was not to reduce the number of instructions, but the complexity, the term has stuck.

There is no precise definition of what constitutes a RISC design. However, we can identify certain characteristics that are present in most RISC systems.

a.

We identify these RISC design principles after looking at why the designers took the route of CISC in the first place.

b.

Because CISC and RISC have their advantages and disadvantages, modern processors take features from both classes. For example, the PowerPC, which follows the RISC philosophy, has quite a few complex instructions. (2) Pipelining. A technique that allows for simultaneous execution of parts, or stages, of instructions to more efficiently process instructions;

( Another general goal was to provide every possible addressing mode for every instruction, known as orthogonality, to ease compiler implementation.

Arithmetic operations could therefore often have results as well as operands directly in memory (in addition to register or immediate).

The attitude at the time was that hardware design was more mature than compiler design so this was in itself also a reason to implement parts of the functionality in hardware and/or microcode rather than in a memory constrained compiler (or its generated code) alone. This design philosophy became retroactively termed Complex Instruction Set Computer (CISC) after the RISC philosophy came onto the scene.

An important force encouraging complexity was very limited main memories (on the order of kilobytes). It was therefore advantageous for the density of information held in computer programs to be high, leading to features such as highly encoded, variable length instructions, doing data loading as well as. These issues were of higher priority than the ease of decoding such instructions.

An equally important reason was that main memories were quite slow (a common type was ferrite core memory); by using dense information packing, one could reduce the frequency with which the CPU had to access this slow resource.

Modern computers face similar limiting factors: main memories are slow compared to the CPU and the fast cache memories employed to overcome this are instead limited in size. This may partly explain why highly encoded instruction sets have proven to be as useful as RISC designs in modern computers.

Designers make choices based on the available technology. As the technology, both hardware and software, evolves, design choices also evolve.

Furthermore, as we get more experience in designing processors, we can design better systems. The RISC proposal was a response to the changing technology and the accumulation of knowledge from the CISC designs. CISC processors were designed to simplify compilers and to improve performance under constraints such as small and slow memories. The important observations that motivated designers to consider alternatives to CISC designs were a.

Simple Instructions. The designers of CISC architectures anticipated extensive use of complex instructions because they close the semantic gap. In reality, it turns out that compilers mostly ignore these instructions. Several empirical studies have shown tha
