DNN driven Speaker Independent Audio-Visual Mask Estimation for Speech Separation

DNN driv en Speaker Independent A udio-V isual Mask Estimation f or Speech Separation Mandar Gogate 1 , Ahsan Adeel 1 , Ricar d Marxer 2 , 3 , J on Barker 3 , Amir Hussain 1 1 Uni versity of Stirling, UK, 2 Uni versit ´ e de T oulon, Aix Marseille Uni v , CNRS, LIS, Marseille, France 3 Uni versity of Shef field, UK mandar.gogate@stir.ac.uk Abstract Human auditory cortex e xcels at selectiv ely suppressing back- ground noise to focus on a target speaker . The process of selec- tiv e attention in the brain is kno wn to contextually exploit the av ailable audio and visual cues to better focus on target speak er while filtering out other noises. In this study , we propose a nov el deep neural network (DNN) based audiovisual (A V) mask estimation model. The proposed A V mask estimation model contextually integrates the temporal dynamics of both audio and noise-immune visual features for improved mask estima- tion and speech separation. For optimal A V features extraction and ideal binary mask (IBM) estimation, a h ybrid DNN archi- tecture is exploited to le verages the complementary strengths of a stacked long short term memory (LSTM) and conv olution LSTM network. The comparative simulation results in terms of speech quality and intelligibility demonstrate significant per - formance improv ement of our proposed A V mask estimation model as compared to audio-only and visual-only mask esti- mation approaches for both speaker dependent and independent scenarios. Index T erms : Speech Separation, Binary Mask Estimation, Deep Neural Network, Speech Enhancement 1. Introduction Speech separation has received much attention in recent years due to its application in a wide range of real-world problems, ranging from automatic speech and speaker recognition, voice activity detection, to signal to noise ratio (SNR) estimation and noise reduction in hearing aids [1, 2]. In the literature, there are two widely used speech separation approaches: (1) Statistical model based background noise estimation such as spectral sub- traction, W iener filtering, and linear minimum mean square er- ror (2) Computational auditory scene analysis (CASA) inspired by the perceptual principles of auditory scene analysis. It is well known that the statistical methods remain deficient in achiev- ing enhanced speech intelligibility , since it introduces distortion such as musical noise. In contrast, CASA has shown to be effec- tiv e in both stationary and non-stationary noises [3]. In CASA, speech is separated by applying a spectral mask to the time- frequency (T -F) representation of a noisy speech. The idea is to suppress the noise-dominant re gions where background noise is stronger than target speech. The IBM is defined from the T -F representation of a speech mixture as follows: I B M ( t, f ) = ( 1 if S N R ( t, f ) > LC 0 other wise . (1) The IBM assigns unit value to a T -F unit if the local SNR within unit exceeds the local criterion (LC), and 0 otherwise. Resynthesis Enhanced Speech Noisy Speech Estimated IBM Video DNN Figure 1: System overview: A udio-V isual Mask Estimation for Speech Separ ation The IBM has shown to improve the overall speech quality and intelligibility for normal-hearing and hearing-impaired listeners [4, 5]. In real world scenarios, IBM cannot be calculated using equation 1. Howev er , the problem can be modelled as a data- driv en binary classification problem that uses noisy speech to estimate the IBM. In the literature, extensi ve research has been carried out to de velop speech separation methods for speech recognition [6, 7]. Researchers ha ve proposed sev eral dif ferent speech separation models such as parametric mask estimation meth- ods [8, 9, 10], neural network based mask estimation meth- ods [11, 12], and nov el loss functions [13]. Howe ver , lim- ited work has been conducted to develop robust speaker inde- pendent audio-visual speech separation models to perform en- hancement. The fe w attempts to address this problem ha ve been restricted to speaker dependent scenarios. In [13], audio and vi- sual features are first concatenated into a single vector . The concatenated vector is then used to train a non-causal speaker- dependent DNN with a perceptually motiv ated loss function in- spired by the hit minus false-alarm (HIT -F A) rate. In addition, [14] proposed an audio-based blind source separation to extract the tar get speaker from speech mixture. The permutation and scaling ambiguities present in the estimated signal are corrected using visual speech information. In supervised learning, generalisation to unseen data is a critical issue. One of the major issues of supervised speech sep- aration are noise and speaker generalisation. It has been shown that giv en enough training noises, a DNN generalises well to unseen ones [15]. Howev er , the generalisation capability to unseen speakers with an unknown noise remains a challenging task. In addition, it has been sho wn that, the concatenation of raw unimodal features into a single vector degrades the overall performance of the supervised learning system [16]. In this study , we propose a unified model that separates speech of an unseen speaker from an unknown noise. The dev el- oped hybrid DNN model integrated a stacked LSTM and Con- LSTM LSTM LSTM LSTM LSTM LSTM LSTM LSTM LSTM LSTM LSTM LSTM Fusion Estimated IBM Visual Frames Conv Pool Conv Pool Conv Pool Conv Pool Fully Connected (1024) LSTM LSTM LSTM LSTM LSTM LSTM Visual Featur es Acoustic Features t k-5 t k-4 t k-3 t k-2 t k-1 t k Input Acostic Features Fully Connected (622) t k-5 - t k Figure 2: Pr oposed Multimodal Mask Estimation Model volutional LSTM network for optimised A V mask estimation, taking into account the temporal dynamics of both audio and visual data. The dev eloped model exploits the long-term con- textual dependencies to better focus on the target speaker . An ov erview of our proposed A V driv en mask estimation model is shown in Figure 1. The hybrid DNN model effectiv ely learns the correlation between noisy A V features and IBM in order to produce an estimate of noise and speech dominant regions. The estimated IBM retains the speech dominant T -F units and suppresses the noise dominant T -F units. Finally , the enhanced speech is resynthesised by combining processed signal across frequency channels. The rest of the paper is organised as follo ws: Section 2 presents the dataset and preprocessing. Section 3 presents the proposed DNN driven A V mask estimation. Section 4 explains the experimental results. Finally , Section 5 concludes this work. 2. A V Dataset and pre-pr ocessing 2.1. Dataset In our experiments, the widely used benchmark Grid Corpus [17] is used. For preliminary analysis, 5 speakers are consid- ered (speaker 1, 6, 7, 15 and 26) each reciting around 1000 utterances, and each sentence consists of a six word sequence of the form indicated in T able 1. The clean Grid utterances are mixed with random highly non-stationary noises (bus, cafe, street, pedestrian) from 3rd CHiME Challenge (CHiME3)[18] for dif ferent SNR le vels ranging from -12dB to 6dB with a step size of 6dB. It is to be noted that, all the models used were SNR-independent: all the utterances mixed at all SNR levels were employed for training and testing. Specifically , two different models were trained: (1) speaker dependent (2) speaker independent 1. Speaker Dependent : In speaker dependent analysis, 3000 utterances from all 5 speakers were used for train- ing and validation of the DNN model, with a validation split of 20%. The trained network was evaluated on a test set of 2 seen speakers (15 and 26). 2. Speaker Independent : In speaker independent analysis, 3000 utterances from 3 speakers (1, 6 and 7) were used for training and validation of the DNN model, with a val- idation split of 20%. The trained network was evaluated on a test set of 2 unseen speakers (15 and 26). T able 1: GRID sentence grammar command colour preposition letter digit adverb bin blue at A-Z 1-9 again lay green by minus W zero now place red in please set white with soon 2.2. Pre-processing A udio : The noisy audio signal is sampled at 16kHz and segmented into N 80 ms frames with 1200 samples per frame and 25% increment rate. A Short T ime Fourier Transform (STFT) and hamming windo w is applied to produce 622-bin power spectrum. V ideo : The speakers’ lip images are extracted out of the GRID Corpus videos (recorded at 25 frames per second) using a V iola-Jones lip detector [19] and an object tracker [20]. A region of 92 x 50 was selected around the lip centre. In addition, the extracted lip sequences were upsampled by 3 to match the 75 vectors per second (VPS) rate for audio files. 3. DNN driven A V Mask Estimation This section describes the network architecture, depicted in Fig- ure 2. The network shown ingests preprocessed audio and vi- sual features of time instance t k , t k − 1 , ... , t k − 5 (k is the current time instance and 5 is the number of prior visual frames). The network consists of three main components: (1) Audio Feature Extraction (2) V isual Feature Extraction, and (3) Mul- timodal Fusion. 3.1. A udio feature extraction The preprocessed po wer spectra of time instances t k to t k − 5 were fed into a two layered stacked LSTM network consisting of 1024 cells each. A dropout of 0.2 was applied after each LSTM layer to pre vent the network from overfitting the train data. The last outputs of the 2nd LSTM layer were used as acoustic features for multimodal fusion. PESQ Improvement 0 0.4 0.8 1.2 1.6 -12dB -6dB 0dB 6dB Visual-only Audio-only Audio-Visual IBM Figure 3: PESQ impr ovement computed from the r econstructed speech signal using V isual-only , Audio-only , Audio-visual mask estimation methods, and IBM for unseen speakers 3.2. Visual featur e extraction The e xtracted and preprocessed lip-re gions were fed into a con- volution LSTM model. The model has input dimensions of W x 50 x 92, where W is the number of prior visual frames. Con vo- lution filters are applied to these concatenated utterances. The CNN has a total of 8 layers: 4 con volution and 4 max pooling layers, consisting 32, 64, 64, and 128 feature maps. Moreover , each conv olution uses filters of size 3 x 3 , follo wed by a max pooling layer with a window size of 2 x 2. The individual fea- ture maps e xtracted from the last max pooling layer were fed into a LSTM network with 1024 cells. The LSTM outputs were used as visual features for multimodal fusion. 3.3. Multimodal fusion The optimal features extracted from audio (1024-d) and visual (1024-d) modalities were concatenated into a single vector . The concatenated vector (2048-d) was fed into a fully connected multi-layered perceptron (MLP) network. The MLP consists of two layers having 1024 (ReLU function) and 622 (Sigmoidal function) neurons each. The multimodal fusion method ex- ploited the complementary strengths of both early and late fu- sions. It is to be noted that the audio (A) only and video (V) only mask estimation models were constructed by eliminating the visual and audio feature extraction parts from the networks respectiv ely . It is worth mentioning that no thresholding was applied and sigmoidal outputs were considered as the estimated mask. 4. Results 4.1. Experimental Setup For audiovisual cues integration and mask estimation, deep learning based data-driv en approaches are trained and v alidated using T ensorflow library and 4 NVIDIA Titan X Pascal GPUs with 12GB of GDDR5X memory each. A subset of dataset is used for training/v alidation of the neural network (80% train- ing dataset) and rest of the data is used to test the performance of the trained neural network in unseen scenarios (20% test- ing dataset). The pre-processed training set of A V corpus con- sists of around 3000 utterance, which are further split into 2400 and 600 utterances for training and validation respecti vely . The dataset consists of visuals and noisy audio frames as input to (a1) Ideal binary mask (speaker independent) (a2) Estimated IBM (speaker independent) (b1) Ideal binary mask (speaker dependent) (b2) Estimated IBM (speaker dependent) Figure 4: Ideal binary mask and Estimated IBM by DNN, for (a) Speaker Independent (b) Speaker Dependent cases the learning model and IBM as an output. T raining was per- formed using backpropogation with the Adam optimiser [21]. The DNN performances are e v aluated using classification ac- curacy of T -F units and perceptual ev aluation of speech quality (PESQ) score. 4.2. Time-Frequency Classification Results The classification results of our proposed DNN models are sum- marised in T able 2. It can be seen that going from low SNRs to high SNRs, the classification accuracy decreases linearly for all deep learning models (A-only , V -only , and A V) in both speaker dependent and independent scenarios. It is mainly because of the total number of 0’ s and 1’ s for each case, where at low SNRs there are less transitions as compared to transitions at higher SNRs. Overall, A V driv en mask estimation model significantly outperformed both A-only and V -only driven mask estimation models, where V -only achie ved the least classification accurac y for all SNRs in both speaker dependent and independent cases. It is worth mentioning that A V dri ven mask estimation achie ved the highest accuracy of 95.5%, 94.8%, and 92.1% at -12dB, - 6dB, and 0dB SNRs respectiv ely . 4.3. Objective testing In order to objectively measure the quality of re-synthesised speech, a widely used PESQ test is used. PESQ is an mean opin- ion score (MOS) like ev aluation, though correlation between subjectiv e MOS test and PESQ test is not very high. Howe ver , among all objectiv e measures, PESQ is one of the reliable meth- ods to ev aluate speech quality . The PESQ score is computed as a linear combination of the average disturbance value and the av erage asymmetrical disturbance values. The PESQ score ranges from -0.5 to 4.5 corresponding to low to high speech quality . The PESQ results for A-only , V -only , and A V models are presented in T able 3 for both speaker dependent and inde- T able 2: Mask estimation r esults (T -F classification accuracy): Comparison of audio-only , visual-only , and audio-visual mask estima- tion models SNR Speaker Dependent Speaker Independent V isual-only A udio-only Audio-V isual V isual-only A udio-only A udio-Visual -12dB 92.8 96.7 97.5 92.1 92.1 95.5 -6dB 91.6 95.5 96.9 90.8 90.1 94.8 0dB 90.5 94.2 96.1 89.7 88.6 92.1 6dB 86.5 93.7 95.6 84.9 85.2 89.9 T able 3: PESQ scores: Comparison of audio-only , visual-only, and audio-visual mask estimation models with IBM and noisy speec h SNR Speaker Dependent Speaker Independent V isual-only A udio-only Audio-V isual V isual-only A udio-only A udio-Visual Noisy IBM -12dB 1.21 1.72 2.18 1.09 1.61 1.87 1.018 2.21 -6dB 1.30 1.95 2.34 1.23 1.84 2.05 1.07 2.38 0dB 1.52 2.14 2.42 1.36 2.05 2.17 1.08 2.53 6dB 1.73 2.33 2.53 1.51 2.23 2.34 1.09 2.69 pendent cases. It can be seen that in speaker independent sce- nario, A V significantly outperformed A-only and V -only mask estimation models, where A V model achieved the PESQ scores of 1.87, 2.05, and 2.17 at SNRs le vels of -12dB, -6dB, and 0 dB respectiv ely , as compared to 1.09, 1.23, and 1.36 achie ved by V -only and 1.61, 1.84, and 2.05 achiev ed by A-only mask estimations. At high SNR (6dB), A V mask estimation achieved PESQ score of 2.34, as compared to 2.23 and 1.51 achieved by A-only and V -only dri ven mask estimations respectively . The ov erall PESQ improv ement as compared to noisy audio is de- picted in Figure 3, where A V -driven mask estimation signifi- cantly outperformed the A-only and V -only driven mask esti- mation models, and achie ved near optimal performance (close to IBM). Figure 4 presents the IBM and estimated IBM by DNN of a randomly selected utterance, where the quality of mask es- timation is apparent (i.e. close to the ideal). 5. Conclusions This paper presented a novel DNN based A V mask estima- tion model that conte xtually integrates and exploits the tem- poral dynamics of both audio and visual features for enhanced mask estimation and speech separation. The multimodal hy- brid DNN architecture exploited the complementary strengths of both early and late fusions using LSTM and CLSTM net- works. The performance evaluation in terms of mask estimation accuracy , speech quality , and speech intelligibility revealed sig- nificant performance improv ement of our proposed A V model as compared to both A-only and V -only driven mask estima- tion models. Specifically , A V driven mask estimation achieved the highest accuracy of 95.5%, 94.8%, and 92.1% at -12dB, - 6dB, and 0dB SNRs respectiv ely in speaker independent scenar- ios. The mask estimation improvement also reflected in PESQ speech quality evaluation, where A V -driven mask estimation significantly outperformed the A-only and V -only driven mask estimation models, and achieved near optimal speech enhance- ment performance. It is worth mentioning that the Grid corpus is very re gular and could help achieving higher accuracy . In future, we intend to in vestigate the generalisation capability of our proposed DNN model with more other more challenging audiovisual corpora. 6. Acknowledgements This work was supported by the UK Engineering and Physical Sciences Research Council (EPSRC) Grant No. EP/M026981/1. W e gratefully acknowledge the support of Prof. Hadi Larijani from Glasgow Caledonian Uni versity and NVIDIA Corporation for providing access to the Titan X P as- cal GPUs for this research. 7. References [1] A. Narayanan and D. W ang, “Inv estigation of speech sep- aration as a front-end for noise robust speech recognition, ” IEEE/ACM T ransactions on Audio, Speech, and Language Pro- cessing , vol. 22, no. 4, pp. 826–835, 2014. [2] H. Kayser, C. Spille, D. Marquardt, and B. T . Meyer, “Improving automatic speech recognition in spatially-aw are hearing aids, ” in Sixteenth Annual Confer ence of the International Speec h Commu- nication Association , 2015. [3] J. Chen and D. W ang, “Dnn based mask estimation for supervised speech separation, ” in Audio sour ce separ ation . Springer , 2018, pp. 207–235. [4] M. Ahmadi, V . L. Gross, and D. G. Sine x, “Perceptual learning for speech in noise after application of binary time-frequency masks, ” The Journal of the Acoustical Society of America , vol. 133, no. 3, pp. 1687–1692, 2013. [5] D. W ang, U. Kjems, M. S. Pedersen, J. B. Boldt, and T . Lun- ner , “Speech intelligibility in background noise with ideal binary time-frequency masking, ” The Journal of the Acoustical Society of America , vol. 125, no. 4, pp. 2336–2347, 2009. [6] H. Erdogan, J. R. Hershey , S. W atanabe, and J. Le Roux, “Deep recurrent networks for separation and recognition of single- channel speech in nonstationary background audio, ” in New Era for Robust Speec h Recognition . Springer , 2017, pp. 165–186. [7] A. Narayanan and D. W ang, “Ideal ratio mask estimation us- ing deep neural networks for robust speech recognition, ” in 2013 IEEE International Confer ence on Acoustics, Speech and Signal Pr ocessing , May 2013, pp. 7092–7096. [8] N. Ito, S. Araki, and T . Nakatani, “Permutation-free con volu- tiv e blind source separation via full-band clustering based on frequency-independent source presence priors, ” in 2013 IEEE In- ternational Confer ence on Acoustics, Speech and Signal Pr ocess- ing , 2013. [9] N. Ito, S. Araki, T . Y oshioka, and T . Nakatani, “Relaxed disjoint- ness based clustering for joint blind source separation and dere- verberation, ” in Acoustic Signal Enhancement (IW AENC), 2014 14th International W orkshop on . IEEE, 2014, pp. 268–272. [10] D. H. T . V u and R. Haeb-Umbach, “Blind speech separation employing directional statistics in an expectation maximiza- tion framework, ” in Acoustics Speech and Signal Processing (ICASSP), 2010 IEEE International Confer ence on . IEEE, 2010, pp. 241–244. [11] J. Heymann, L. Drude, and R. Haeb-Umbach, “Neural network based spectral mask estimation for acoustic beamforming, ” in Acoustics, Speech and Signal Pr ocessing (ICASSP), 2016 IEEE International Confer ence on . IEEE, 2016, pp. 196–200. [12] J. Chen and D. W ang, “Long short-term memory for speaker gen- eralization in supervised speech separation, ” The Journal of the Acoustical Society of America , vol. 141, no. 6, pp. 4705–4714, 2017. [13] D. W ebsdale and B. Milner , “ A comparison of perceptually moti- vated loss functions for binary mask estimation in speech separa- tion, ” in Interspeech 2017, 18th Annual Confer ence of the Inter- national Speech Communication Association, Stoc kholm, Sweden, August 20-24, 2017 , 2017, pp. 2003–2007. [14] Q. Liu, W . W ang, and P . Jackson, “ Audio-visual conv olutiv e blind source separation, ” in Sensor Signal Pr ocessing for Defence (SSPD 2010) , Sept 2010, pp. 1–5. [15] J. Chen, Y . W ang, S. E. Y oho, D. W ang, and E. W . Healy , “Large-scale training to increase speech intelligibility for hearing- impaired listeners in no vel noises, ” The Journal of the Acoustical Society of America , vol. 139, no. 5, pp. 2604–2612, 2016. [16] M. Gogate, A. Adeel, and A. Hussain, “ A novel brain-inspired compression-based optimised multimodal fusion for emotion recognition, ” in 2017 IEEE Symposium Series on Computational Intelligence (SSCI) , Nov 2017, pp. 1–7. [17] M. Cooke, J. Barker, S. Cunningham, and X. Shao, “ An audio- visual corpus for speech perception and automatic speech recog- nition, ” The Journal of the Acoustical Society of America , vol. 120, no. 5, pp. 2421–2424, 2006. [18] J. Barker , R. Marxer , E. V incent, and S. W atanabe, “The third chimespeech separation and recognition challenge: Dataset, task and baselines, ” in Automatic Speech Recognition and Understand- ing (ASR U), 2015 IEEE W orkshop on . IEEE, 2015, pp. 504–511. [19] P . V iola and M. Jones, “Rapid object detection using a boosted cascade of simple features, ” in Computer V ision and P attern Recognition, 2001. CVPR 2001. Proceedings of the 2001 IEEE Computer Society Confer ence on , vol. 1. IEEE, 2001, pp. I–511. [20] D. A. Ross, J. Lim, R.-S. Lin, and M.-H. Y ang, “Incremental learning for rob ust visual tracking, ” International Journal of Com- puter V ision , vol. 77, no. 1-3, pp. 125–141, 2008. [21] D. P . Kingma and J. Ba, “ Adam: A method for stochastic opti- mization, ” arXiv pr eprint arXiv:1412.6980 , 2014.
