Device-dir ected Utterance Detection Sri Harish Mallidi, Roland Maas, K yle Goehner , Ariya Rastr ow , Spyr os Matsoukas, Bj ¨ orn Hoffmeister Amazon, USA { mallidih,rmaas,kgoehner,arastrow,matsouka,bjornh } @amazon.com Abstract In this work, we propose a classifier for distinguishing device-directed queries from background speech in the context of interactions with voice assistants. Applica- tions include rejection of false wake-ups or unintended interactions as well as enabling wake-w ord free follow- up queries. Consider the example interaction: “Com- puter , play music”, “Computer , r educe the volume” . In this interaction, the user needs to repeat the wake-w ord ( Computer ) for the second query . T o allo w for more nat- ural interactions, the device could immediately re-enter listening state after the first query (without wake-word repetition) and accept or reject a potential follow-up as device-directed or background speech. The proposed model consists of two long short-term memory (LSTM) neural networks trained on acoustic features and auto- matic speech recognition (ASR) 1-best hypotheses, re- spectiv ely . A feed-forward deep neural network (DNN) is then trained to combine the acoustic and 1-best embed- dings, deriv ed from the LSTMs, with features from the ASR decoder . Experimental results show that ASR de- coder , acoustic embeddings, and 1-best embeddings yield an equal-error -rate (EER) of 9 . 3 % , 10 . 9 % and 20 . 1 % , respectiv ely . Combination of the features resulted in a 44 % relativ e improvement and a final EER of 5 . 2 % . Index T erms : speech recognition, human-computer in- teraction, computational paralinguistics 1. Introduction The popularity of voice controlled far-field devices (e.g. Amazon Echo, Google Home) is on rise. These de vices are often used in challenging acoustic environments. One such example is a living room scenario, where the de- vice may capture speech from several speakers (not just the device user’ s speech) and multi-media speech (speech from TV or music player). In these situations, it is cru- cial for the device to act only on the intended (referred to as de vice-directed) speech and ignore un-intended (re- ferred to as nonde vice-directed) speech. In order to make the voice controlled device robust to nondevice-directed speech, a reliable device-directed vs nonde vice-directed classifier is required, which we will in vestigate in this work. Past research on device-directed speech detection re- lied on acoustic features in addition to features from an ASR decoder [1, 2, 3, 4, 5]. Acoustic features used in these works are primarily related to prosodic structure of input speech. Energy and pitch trajectories, speak- ing rate, and duration information are computed and sev eral statistics of these features are used for de vice- directed speech detection [1]. Non-traditional acoustic features such as multi-scale Gabor wa velets have also been explored in [3]. Features from non-acoustic sources like ASR confidence scores, N-grams have been used in [1, 3, 6]. A variety of classifiers are then used to model the extracted features, and their decisions are combined during inference. In this work, we use three sources of information: (i) acoustics, (ii) ASR decoder , and (iii) ASR 1-best hypoth- esis. T wo LSTM models are trained on acoustics and 1-best word/character sequences, respectively , to obtain fixed length embeddings. A single feature vector per ut- terance is then constructed by concatenating these em- beddings with features from ASR decoder . A fully con- nected neural network is trained on utterance feature. The paper is org anized as follows: Section 2 pro vides an overvie w of the proposed de vice-directed model. In this section, we also discuss the components in the model. Experimental analyses and results of the proposed model are discussed in Section 3. This section also provides details of the dataset used to train the models. Section 4 presents conclusions of the paper . 2. System architectur e Figure 1 illustrates the model we use for the device- directed detection. This architecture has been proposed for end-pointing task in [7]. The model consists of 4 main components (i) acoustic embedding using LSTM, (ii) ASR decoder features, (iii) character embedding us- ing LSTM, and (iv) classification layer . 2.1. Acoustic embedding The task here is to assign a single label (device-directed or nondevice-directed) to the given utterance. A fixed length v ector of the utterance is obtained as follows: Short-term acoustic features, i.e. log filter-bank energies (LFBEs), are obtained using analysis window length of 25 milliseconds and 10 milliseconds shift. An LSTM fea tu re s fr om ASR decoder ! " device-directed #( |& 1 , & 2 , ⋯ , & + ) Figure 1: Proposed device-dir ected model, based on the combination of three features types: acoustic embedding, 1-best hypothesis embedding, and decoder featur es. model is trained on LFBEs to predict frame-le vel de vice- directed targets. The frame-lev el targets are obtained by repeating the utterance label. The parameters of the LSTM are optimized by minimizing the cross-entropy loss, using stochastic gradient descent [8, 9]. W e use the pre-softmax output of the last frame of input utterance as its representation, since it encodes all the information in the utterance (due to recurrence). This 2-dimensional vector is referred to as acoustic embedding ( a ) of the ut- terance. 2.2. ASR decoder features Along with LSTM embeddings, we also use features ob- tained from ASR decoder . These are described below: In ASR, trellis can be used to efficiently estimate HMM parameters and infer the most likely state se- quence. Trellis structure can be used to effecti vely com- pute forward probabilities. Entropy of the forward prob- ability distribution is computed at e very frame, and these are av eraged. A trellis with high entropy indicate that T able 1: P erformance of acoustic LSTM model with r e- spect to number of layers and number of cells in each layer . acoustic LSTM EER(%) # parameters (#layers × #cell size) 3 × 768 13 . 1 12 M 4 × 768 10 . 9 16 M 5 × 768 11 . 0 21 M 6 × 768 11 . 1 26 M 7 × 768 11 . 4 31 M T able 2: Examples of 1-best hypotheses of device- dir ected and nondevice-dir ected utterances. Device-dir ected speech what’ s the weather like in las v egas play popular music mark the first item done what is scratch programming Nondevice-dir ected speech or if they want she can just queue for better well that’ s ho w we had all the training talk to alexa b ut we’ re talking to danny right no w liv e together like months ago and they may still be boring the probability mass is spread over alternate hypotheses, and ASR being less confident about its best hypothesis. This can be due to language model mismatch or acoustic mismatch, which typically indicates nondevice-directed speech. Along with trellis entropy , we extract V iterbi costs [10]. These features indicate ho w well the input acous- tics and vocab ulary match with the acoustic and language models. Higher cost typically indicate greater mismatch between the model and giv en data. A confusion network [11] is a simple linear graph, which is used as an alternati ve representation of the most likely hypotheses of the decoder lattice. The arcs in the confusion network correspond to words. Along with the word ids on each arc, confusion network also contains posterior estimates of each word. ASR confidence of 1- best ASR hypothesis is obtained by taking a geometric product of all the posterior probabilities of words in the 1-best hypothesis [12]. Along with ASR confidence, we compute the av erage number of arcs from each node in the confusion network. This relates to the number of competing hypotheses in the confusion network. Large number of competing hypotheses could indicate that the ASR system is being less confident about the 1-best hy- pothesis. In total we use 18 features from the decoder . W e used our in-house ASR system based on [13, 14] to extract these features, referred to as decoder featur es ( d ). T able 3: P erformance of char LSTM model with respect to the size of character embedding. Embedding dimension EER(%) 50 21 . 0 100 20 . 6 200 20 . 1 300 21 . 3 2.3. Character embedding Similar to acoustic embedding , we extract a fixed length representation from ASR 1-best hypotheses. Character sequence of a 1-best hypothesis is con verted into vec- tor sequence using pre-trained embedding vectors. W e use GloV e embeddings [15] for this purpose. An LSTM is trained on the vector sequence to predict frame-lev el device-directed decisions. Note that frame here refers to a character in the 1-best hypothesis. Once the network is trained, the network output of the last character is used as representation of 1-best hypothesis. This is referred to as char embedding ( c ) of the input utterance. Once the acoustic and char LSTMs [16] are trained, the 2 embeddings are extracted and concatenated with de- coder features to form a 22-dimensional utterance vector ( f = [ a , c , d ] ). This vector is used as input to train a fully connected network (classification layer in figure 1). 3. Experiments W e use real recordings of natural human interactions with voice-controlled far-field de vices for training and testing the models. The training dataset consists of 250 hours of audio data comprised of 350k utterances. Of these, 200k and 150k are device-directed and nonde vice- directed examples, respectiv ely . The test data consists of 50k utterances (30 hours of audio data), with 38k device-directed and 12k nondevice-directed utterances. The classification performance is ev aluated in terms of equal-error-rate (EER %). EER correspond to the point on detection-error-tradeof f (DET) curve where false positiv e rate is equal to false negati ve rate. W e also report DET curve to asses whether the improvement is consistent across sev eral operating points. T able 4: Device-dir ected performance using various fea- tur es. features EER(%) decoder features ( d ) 9 . 3 acoustic embedding ( a ) 10 . 9 char embedding ( c ) 20 . 1 [ a , d ] 6 . 5 [ c , d ] 6 . 9 [ a , c ] 8 . 6 [ a , c , d ] 5 . 2 False positive rate (%) 0 5 10 15 20 25 30 Miss detection rate (%) 0 5 10 15 20 25 30 a d c [ a , c , d ] Figure 2: Detection err or tradeof f (DET) curves of acous- tic embedding ( a ), decoder featur es ( d ), char embedding ( c ), and combination model ( [ a , c , d ] ). 3.1. LSTM architectur e Acoustic LSTM : W e used 64 dimensional LFBEs to train an acoustic LSTM. Number of layers in the network are v aried to find the optimal model architecture. T able 1 shows the EERs of sev eral acoustic LSTMs. It can be inferred from the table that adding more layers to the model improve the performance. Lo west EER is obtained by the model with 4 layers ( 16 M ). Adding more layers does not improve the performance. W e hypothesize that this might be due to not enough training data. Char LSTM : A deeper analysis of device-directed and nondevice-directed utterances indicated that, device- directed speech is structured, containing short phrases and similar words. In comparison, nondevice-directed speech is more spontaneous and less grammatical. This is reflected even in 1-best hypothesis of ASR. T able 2 il- lustrates a few1-best hypotheses. W e can infer from the table that 1-best hypotheses of device-directed speech is markedly different from nondevice-directed speech. In- spired by this, we use embedding of 1-best hypothesis. T able 3 sho ws the EERs of char LSTM models as a func- tion of input embedding size. It can be inferred from the table that a 200 dimensional embedding is optimal for this task. 3.2. Results Comparison between tables 1 and 3 shows that the acous- tic LSTM is performing better than char LSTM. Lower accuracy of char LSTM might due to a smaller amount of training data. The acoustic LSTM is trained on 91 mil- lion frames where as char LSTM is trained on 8 million frames. T able 4 shows the performance of the acoustic LSTM, char LSTM, decoder features, and their combinations. It can observed that decoder features are best performing ( 9 . 1 % EER) follo wed by acoustic LSTM ( 11 % EER) and char LSTM ( 20 % EER). It can also be inferred from the table that the features are complimentary in nature since the combination of features ne ver de grades o ver the single features. The final performance of the proposed model is 5 . 2% EER. Figure 2 shows the DET graphs of individual features and the final combination. It can be inferred that the combination performs better than indi- vidual features in all operating points. 4. Conclusions In this work, we explored acoustic features and features from ASR system for the task of device-directed utter- ance detection. An acoustic embedding vector is ex- tracted by training an LSTM network on LFBEs. From ASR system, we extract sev eral decoder features (trellis entropy , V iterbi costs, etc.). Also, we model 1-best hy- pothesis by first transforming the character sequence into vector sequence (using GloV e embeddings). An LSTM is trained on the resulting vector sequence to obtain a char embedding. Experimental results indicate that acous- tic embedding, char embedding and decoder features are useful for device-directed task. The combination of all 3 features resulted in an 44 % relativ e reduction EER over best individual feature ( 9 . 3 % to 5 . 2 % EER), indicating complementary nature of the features. 5. References [1] E. Shriber g, A. Stolcke, D. Hakkani-Tr, and L. Heck, “Learning when to listen: Detecting system-addressed speech in human-human-computer dialog, ” in Pr oc. In- terspeech . Portland, OR: ISCA - International Speech Communication Association, September 2012, pp. 334– 337. [2] D. Reich, F . Putze, D. Heger , J. Ijsselmuiden, R. Stiefelha- gen, and T . Schultz, “ A real-time speech command detec- tor for a smart control room, ” in Proc. Interspeech , 2011, pp. 2641–2644. [3] T . Y amag ata, T . T akiguchi, and Y . Ariki, “System re- quest detection in human con versation based on multi- resolution gabor wav elet features. ” in INTERSPEECH , 2009, pp. 256–259. [4] H. Lee, A. Stolcke, and E. Shriber g, “Using out-of- domain data for lexical addressee detection in human- human-computer dialog. ” in HLT -NAA CL , 2013, pp. 221– 229. [5] D. W ang, D. Hakkani-T ¨ ur , and G. Tur , “Understand- ing computer-directed utterances in multi-user dialog systems, ” in Acoustics, Speech and Signal Pr ocess- ing (ICASSP), 2013 IEEE International Conference on . IEEE, 2013, pp. 8377–8381. [6] J. Dowding, R. Alena, W . J. Clancey , M. Sierhuis, and J. Graham, “ Are you talking to me? dialogue systems supporting mixed teams of humans and robots, ” in AAAI F all Symposium on Aurally Informed P erformance: Inte- grating Machine Listening and Auditory Pr esentation in Robotic Systems, Arlington, V ir ginia , 2006. [7] R. Maas, A. Rastrow , C. Ma, G. Lang, K. Goehner, G. T iwari, S. Joesph, and B. Hoffmeister , “Combining acoustic embeddings and decoding features for end-of- utterance detection in real-time far -field speech recogni- tion systems, ” in Acoustics, Speech and Signal Pr ocessing (ICASSP), 2018 IEEE International Conference on . [8] Y . LeCun, L. Bottou, G. B. Orr, and K.-R. M ¨ uller , “Effi- cient backprop, ” in Neural networks: T ricks of the trade . Springer , 1998, pp. 9–50. [9] N. Strom, “Scalable distributed DNN training using com- modity GPU cloud computing, ” in Proceedings of Inter- speech , 2015. [10] M. Gales and S. Y oung, “The application of hidden markov models in speech recognition, ” F oundations and tr ends in signal pr ocessing , vol. 1, no. 3, pp. 195–304, 2008. [11] L. Mangu, E. Brill, and A. Stolcke, “Finding consensus in speech recognition: word error minimization and other applications of confusion networks, ” Computer Speech & Language , v ol. 14, no. 4, pp. 373–400, 2000. [12] G. Evermann and P . W oodland, “Posterior probability de- coding, confidence estimation and system combination, ” in Pr oc. Speech T ranscription W orkshop , vol. 27. Balti- more, 2000, pp. 78–81. [13] S. H. K. Parthasarathi, B. Hoffmeister , S. Matsoukas, A. Mandal, N. Strom, and S. Garimella, “fMLLR based feature-space speaker adaptation of DNN acoustic mod- els, ” in Pr oceedings Interspeec h , 2015. [14] S. Garimella, A. Mandal, N. Strom, B. Hoffmeister , S. Matsoukas, and S. H. K. P arthasarathi, “Rob ust i-vector based adaptation of DNN acoustic model for speech recognition, ” in Pr oceedings Interspeec h , 2015. [15] J. Pennington, R. Socher, and C. D. Manning, “Glove: Global vectors for word representation. ” [16] S. Hochreiter and J. Schmidhuber, “Long short-term memory , ” Neural Computation , vol. 9, no. 8, pp. 1735– 1780, 1997.
